1616635681: OFS Q-21 AIR END

We supply the genuine Atlas Copco 1616635681 OFS Q-21 Air End. As an distributor of Atlas Copco products, we source this critical component directly from Atlas Copco (Shanghai) Trading Co., Ltd. , guaranteeing 100% new original quality.

Product Introduction

The OFS Q-21 Air End serves as the heart of your oil-free screw compressor system . This precision-engineered component delivers 100% oil-free compressed air for applications where air purity is absolutely critical. Industries such as food and beverage, pharmaceuticals, electronics manufacturing, and healthcare facilities rely on this air end to maintain product integrity and regulatory compliance .

Atlas Copco applies strict quality control throughout manufacturing and final inspection. Each OFS Q-21 AIR END undergoes dimensional checks and functional validation before release . The advanced coating technology on the rotors ensures minimal internal leakage and maximum efficiency throughout the service life .

Product Specifications

The table below lists the complete technical details for this air end.

Specification	Value
Part Name	OFS Q-21
Part Number	1616635681
Type	Oil-Free Screw Air End
Compatibility	Atlas Copco Oil-Free Rotary Screw Compressors
Origin	Belgium (BE)
Tariff Code	84149090
Weight	904 kg
Width	860 mm
Height	850 mm
Length	1260 mm
Warranty	12 months on design and production defects

Product Benefits

100% Oil-Free Air Quality: The OFS Q-21 design eliminates any risk of oil contamination in your compressed air system. This protects sensitive production processes and final products in critical applications .

Energy Efficiency: Atlas Copco engineers designed this air end with advanced rotor profiles and Teflon-based coating technology. The coating tightens the seal between rotors and housing while reducing friction, delivering up to 20% lower energy consumption compared to refurbished alternatives .

Extended Service Life: Precision machining holds tolerances to a fraction of the diameter of a human hair . This attention to detail, combined with high-quality bearings and seals, ensures thousands of hours of reliable operation.

Genuine Performance Guarantee: Each unit undergoes dimensional checks and functional validation before leaving the factory. You receive 100% genuine Atlas Copco quality with full traceability from Belgium.

12-Month Warranty Protection: We supply this product with Atlas Copco’s 12-month warranty on design and production defects, giving buyers confidence in both performance and after-sales support.

Instructions & Precautions

Precautions

WARNING: Before carrying out any maintenance, repair work, or adjustments, follow these safety steps :

1. Stop the compressor completely and switch off the main isolator
2. Open the isolating switch and lock it in the OFF position
3. Close the air outlet valve and open the manual condensate drain valve
4. Depressurize the system completely. Verify pressure gauges read zero
5. Allow the compressor to cool to ambient temperature before handling
6. Do not attempt to refurbish or rebearing a worn air end. Atlas Copco advises against refurbishment due to the extreme precision required—improper reassembly causes extensive air leaks and performance loss of up to 20%
7. Use only genuine Atlas Copco parts. Any damage caused by unauthorized parts voids the warranty
8. When servicing, replace all removed gaskets, O-rings, and washers with new ones
9. Dispose of used components in an environmentally friendly manner according to local regulations

Step-by-Step Replacement Procedure

1. System Preparation

• Perform a full system shutdown following the lockout/tagout procedure
• Place a clear “DO NOT OPERATE” tag on the compressor control panel
• Allow the compressor to cool for a minimum of 2 hours after shutdown

2. Remove the Old Air End

• Disconnect all air and oil lines (note: oil-free compressors still have gearbox lubrication)
• Remove the coupling guard and disconnect the drive coupling
• Support the air end with appropriate lifting equipment (weight: 904 kg)
• Remove mounting bolts and carefully extract the old air end from the compressor frame

3. Prepare the New Air End

• Inspect the new OFS Q-21 for any shipping damage
• Verify all ports are sealed and free from debris
• Check that the rotor turns freely by hand

4. Install the New Air End

• Position the new air end using appropriate lifting equipment
• Align the drive coupling precisely—misalignment causes premature bearing failure
• Torque all mounting bolts to manufacturer specifications
• Reconnect all air and oil lines with new gaskets and seals

5. Post-Installation Checks

• Perform a dry run without load to verify smooth operation
• Check for unusual noise or vibration
• Verify operating temperatures and pressures against manufacturer specifications
• Run through a full load cycle while monitoring performance parameters

6. Warranty Registration

• Record the installation date and serial number
• Retain all original packaging and documentation for warranty purposes

Frequently Asked Questions

Q1: Which compressor models is the OFS Q-21 air end compatible with?
A: The OFS Q-21 is designed for Atlas Copco oil-free rotary screw compressors. Contact our technical team with your compressor model and serial number for specific compatibility confirmation.

Q2: Why should I buy a new genuine air end instead of getting my old one refurbished?
A: Atlas Copco advises against refurbishment. The precision tolerances on oil-free air ends are extremely tight—refurbished units often leak and consume up to 20% more energy than new genuine units. The initial savings disappear within approximately 13 months due to higher energy bills .

Q3: How do I verify this OFS Q-21 is genuine from ACD?
A: We source this product strictly from Atlas Copco (Shanghai) Trading Co., Ltd. It arrives in factory-sealed Atlas Copco packaging with full traceability labels, batch numbers, and authenticity seals. You receive 100% genuine new stock.

Q4: What does the 12-month warranty cover?
A: The warranty covers design and production defects. It does not cover misuse, improper fitting, normal wear and tear, or damage caused by using non-genuine spare parts. Keep your purchase documentation for any warranty claims.

Q5: Does ACD provide technical support for installation?
A: Yes. We provide remote technical support and detailed installation guidance. For complex installations, we can recommend certified Atlas Copco service technicians in your region.
