ATLAS COPCO GA45 VSD FF AIR COMPRESSOR INTERAL COMPONENTS

ATLAS COPCO GA22 VSD FF TM AIR COMPRESSOR

ATLAS COPCO GA45 VSD FF AIR COMPRESSOR COMPONENTS

ATLAS COPCO GA45 VSD FF AIR COMPRESSOR APPLICATION

GA 15-45 VSD (FF) Oil-injected Air Compressors

Name: GA 15-45 VSD (FF) Oil-injected Air Compressors - ATLAS COPCO | ACD
Brand: ATLAS COPCO
SKU: 118
Price: 10000.00 USD
Availability: InStock
Rating: 5.00 (3 reviews)

Rated 5.00 out of 5 based on 3 customer ratings

(3 customer reviews)

$10,000.00

Atlas Copco GA 15-45 VSD (FF) Oil-injected Air Compressors (15,18,22,26,30,37,45) combine reliability, low cost of ownership and sustainability in a breakthrough space saving design.

Enquiry

SKU: 118 Category: Oil-injected Air Compressors Tags: Screw Air Compressors, VSD (Variable Speed Drive) Brand: ATLAS COPCO

Working Pressure

4 bar(g) - 10 bar(g)

Capacity FAD

45 m³/h - 518 m³/h

Installed motor power

15 kW - 45 kW

Capacity FAD l/s

12 l/s - 144 l/s

Country of Origin

Lead Time

30-45Days

MOQ

1 Unit

Packaging

Wooden Crate

Product Quality

100% Genuine, 100% Original, Brand New

Transaction Mode

CFR, CIF, CIP, CPT, DAP, DDP, EXW, FCA

Guaranteed Safe Checkout

Atlas Copco GA 15-45 VSD (FF) Oil-injected Air Compressors combine reliability, low cost of ownership and sustainability in a breakthrough space saving design. Now available in 15-45 kW sizes, it offers Variable Speed Drive technology as standard, powered by an IP66 protected iPM (Interior Permanent Magnet) motor and in-house designed element. As a result, the GA 15-45 VSD (FF) reduces your energy consumption by up to 35%, while operating reliably in the harshest conditions.

Performance and efficiency

Energy efficiency

• VSD technology follows your air demand by automatically adjusting the motor speed to give you energy savings of up to 35%.
• Lowered system pressure minimizes energy use.
• Direct drive technology without gears or belt transmission losses optimizes efficiency.
• The iPM motor equals IE5 efficiency standards.

Reliable performance

• Atlas Copco’s proprietary compression element sets the industry standard in compressor performance and reliability.
• The completely enclosed frequency drive and IP-66 protected oil-cooled motor ensure dependable operation, even in tough environments.
• The GA VSD is built with premium components designed to work together optimally

Smart control

• The dedicated inverter was designed specifically for use in air compressors.
• The Elektronikon Touch controller is included as standard, giving you advanced control, monitoring and optimization options.
• Optional SMARTLINK connectivity enables real-time, remote monitoring, data gathering, alerts, and system improvement.
• EQ central compressor control allows you to manage multiple compressors in one system to optimize performance, efficiency, and maintenance.

Engineered for premium iPM performance

Atlas Copco GA 45 VSD Air Compressor Components

①New drive train

• Designed according to IP66.
• New high-efficiency element.
• iPM motor equals IE5 standards.
• Oil-cooled for maximum efficiency.
• No gears or belts means no transmission losses.

②Dedicated inverter

The advanced inverter’s smart control ensures best-in-class energy efficiency and high reliability with STO protection.

③Elektronikon Touch controller

• High-tech controller with warning indications, compressor shutdown and maintenance scheduling.
• Easy to use and designed to perform in the toughest conditions.
• Optional SMARTLINK remote monitoring maximizes air system performance and energy savings.

④Efficient cooling

• Separate oil/air cooler.
• Easy access for maintenance.

⑤Cooling fan

Optimized, application-specific design ensures low noise and high efficiency

⑥Integrated dryer

Optional integrated refrigerant dryer ensures air quality and prevents rust and corrosion in your compressed air network. Its plug-and play design eliminates cost of installing a separate dryer.

VSD technology: up to 35% energy savings

The true cost of owning a compressor – both financially and in terms of sustainability – lies in its energy use. After all, energy takes up 80% of the lifetime cost of a compressor. That makes efficiency the number one requirement to reduce your operational costs and environmental footprint in a meaningful way.

Atlas Copco GA Variable Speed Drive iPM technology closely matches the air demand by automatically adjusting the motor speed. This results in energy savings of up to 35%.

VSD technology: up to 35% energy savings

Fixed-speed

unadaptable energy use

VSD

energy use follows fluctuating demand

Traditional fixed-speed compressors only have one speed, 100% on. The result is a lot of wasted energy when your demand is lower.

Atlas Copco Variable Speed Drive compressors have an inverter that allows them to adjust their motor speed to match the air demand to give you unprecedented energy savings:

• Up to 35% energy savings with an extensive flow range.

• Integrated Elektronikon Touch controller controls the motor speed.

• Advanced inverter built for optimal compressor operation.

• Oil-cooled iPM motor means compressor can start/stop under full system pressure without the need to unload.

• Eliminates peak current penalty during start-up.

Flow charts

GA 15-30 VSD Flow charts	GA 37-45 VSD Flow charts
Flow charts

Technical specifications

Compressor type	Working pressure		*Capacity FAD (min-max)**						Motor power		Noise	Weight			Outlet
Compressor type	bar(e)	psig	l/s		m³/min		cfm		kW	hp	dB(A)	Pack(kg)	FF(kg)	FFTM(kg)
GA 15 VSD	4	58	12	44	0.75	2.64	26	93	15	20	69	227	340	450	G1
	7	102	12	43	0.73	2.59	26	91	15	20	69	227	340	450	G1
	8	116	12	41	0.73	2.44	26	86	15	20	69	227	340	450	G1
	10	145	12	38	0.74	2.29	26	81	15	20	70	227	340	450	G1
GA 18 VSD	4	58	13	59	0.80	3.55	28	125	18	25	69	238	358	460	G1
	7	102	13	58	0.78	3.48	28	123	18	25	69	238	358	460	G1
	8	116	13	55	0.77	3.31	27	117	18	25	69	238	358	460	G1
	10	145	13	49	0.75	2.96	27	105	18	25	70	238	358	460	G1
GA 22 VSD	4	58	13	70	0.81	4.18	29	148	22	30	70	250	372	478	G1
	7	102	13	68	0.79	4.10	28	145	22	30	70	250	372	478	G1
	8	116	14	66	0.82	3.95	29	139	22	30	70	250	372	478	G1
	10	145	14	61	0.87	3.65	31	129	22	30	71	250	372	478	G1
GA 26 VSD	4	58	13	80	0.76	4.82	27	170	26	35	74	329	435	N/A	G1
	7	102	12	79	0.74	4.73	26	167	26	35	74	329	435	N/A	G1
	8	116	12	76	0.74	4.53	26	160	26	35	75	329	435	N/A	G1
	10	145	12	69	0.74	4.14	26	146	26	35	76	329	435	N/A	G1
GA 30 VSD	4	58	20	93	1.23	5.57	43	197	30	40	72	359	465	N/A	G1 1/2
	7	102	20	93	1.21	5.55	43	196	30	40	72	359	465	N/A	G1 1/2
	8	116	21	89	1.23	5.35	44	189	30	40	72	359	465	N/A	G1 1/2
	10	145	21	82	1.29	4.94	45	174	30	40	73	359	465	N/A	G1 1/2
GA 37 VSD	4	58	20	118	1.22	7.05	43	249	37	50	74	379	562	N/A	G1 1/2
	7	102	20	117	1.19	7.02	42	248	37	50	74	379	562	N/A	G1 1/2
	8	116	20	112	1.22	6.74	43	238	37	50	74	379	562	N/A	G1 1/2
	10	145	21	103	1.26	6.17	44	218	37	50	75	379	562	N/A	G1 1/2
GA 45 VSD	4	58	30	144	1.78	8.64	63	305	45	60	75	427	610	N/A	G1 1/2
	7	102	29	143	1.74	8.59	61	303	45	60	75	427	610	N/A	G1 1/2
	8	116	37	137	2.23	8.24	79	291	45	60	75	427	610	N/A	G1 1/2
	10	145	38	116	2.29	6.97	81	246	45	60	76	427	610	N/A	G1 1/2

** Unit performance measured according to ISO 1217 ed. 4 2009, annex E, latest edition.
** Mean noise level measured at a distance of 1 m at max. working pressure according to ISO 2151: 2004 using ISO 9614/2 (sound intensity method); tolerance 3 dB(A).

Reference conditions:
– Absolute inlet pressure 1 bar (14.5 psi)
– Intake air temperature 20°C/68°F

FAD is measured at the following effective working pressures:
– 4 bar(e)
– 7 bar(e)
– 8 bar(e)
– 10 bar(e)

Dimensions

ATLAS COPCO GA22 VSD FF TM AIR COMPRESSOR	Dimensions (WxDxH)	Pack (mm)	Full Feature (mm)	Full Feature Tank-mounted (mm)
	GA 15-22 VSD	700 x 700 x 1470	700 x 1230 x 1470	700 x 1950 x 1911
	GA 26-45 VSD	870 x 840 x 1720	870 x 1465 x 1720	N/A

Options

• FoodGrade oil
• UD+ air filter
• IT ancillaries
• WSD water separator
• SMARTLINK remote connectivity

Atlas Copco GA 15-45 VSD (FF) Oil-injected Air Compressors Brochure

If you need Atlas Copco GA 15-45 VSD (FF) Oil-injected Air Compressors brochure, please click the link below to view or download it.

GA15-45 VSD Sales Leaflet EN Wuxi 2026

Inquiry Now

Contact Form Demo

Name

Country

Message

Weight	300.00 kg
Dimensions	87 × 84 × 172 cm
Working Pressure	4 bar(g) – 10 bar(g)
Capacity FAD	45 m³/h – 518 m³/h
Installed motor power	15 kW – 45 kW
Capacity FAD l/s	12 l/s – 144 l/s
Country of Origin	CN
Lead Time	30-45Days
MOQ	1 Unit
Packaging	Wooden Crate
Product Quality	100% Genuine, 100% Original, Brand New
Transaction Mode	CFR, CIF, CIP, CPT, DAP, DDP, EXW, FCA
